हाईडेन्सिटी पॉलीइथिलिन पाईप - एचडीपीई

वर्जिन पाईप ग्रेड रॉ मटेरियल से निर्मित (पीई 80, पीई 100 )
सर्वश्रेष्ठ संक्षारण और रसायन प्रतिरोधकता, अधिकांश अम्लीय व क्षारीय रसायनों के प्रति अक्रियाशील
उच्चप्रवाह अभिलक्षण
वजन में हलके
संभालने व परिवहन में आसानी
सर्वश्रेष्ठ लचीलापन मजबूती सहित
श्रेष्ठ अपघर्षण प्रतिरोधकता
चिकनी अन्दरूनी सतह, कमसे कम घर्षण ह्रास
पेयजल के लिये सर्वथा सुरक्षित
आइएस-4984, आइएसओ-4427, डीआइएन-8074, एएसटीएम-3035 और बीएस-6437 मानक के अनुरूप पीई-63, पीई-80 और पीई-100 मटेरियल ग्रेड मे निर्मित
20 मिमी से 1600 मिमी साईज में विभिन्न प्रेशर रेटिंग 2.5 से 16 किग्रा/सेमी2 (35.5 से 227.5 PSI) में निर्मित
6 इंच तक सीधी लम्बाई और कॉइल में उपलब्ध, बडी साईज मानक लम्बाई में और अन्य सिर्फ सीधी लम्बाई में उपलब्ध।

PE Pipe as per ISO:4427:96
Material Grade PE 63

OD		PN 3.2		PN 4		PN 6		PN 6.3		PN 8		PN10		PN12.5		PN16
OD		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness
Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.
16.0	16.3	-	-	-	-	-	-	-	-	-	-	2.3	2.8	2.3	2.8	2.3	2.8
20.0	20.3	-	-	-	-	-	-	-	-	2.3	2.8	2.3	2.8	2.3	2.8	2.8	3.3
25.0	25.3	-	-	-	-	2.3	2.8	2.3	2.8	2.3	2.8	2.3	2.8	2.8	3.3	3.5	4.1
32.0	32.3	-	-	-	-	2.3	2.8	2.3	2.8	2.4	2.9	2.9	3.4	3.6	4.2	4.4	5.1
40.0	40.4	-	-	2.3	2.8	2.3	2.8	2.4	2.9	3.0	3.5	3.7	4.3	4.5	5.2	5.5	6.4
50.0	50.5	-	-	2.3	2.8	2.9	3.4	3.0	3.5	3.7	4.3	4.6	5.3	5.6	6.5	6.9	8.0
63.0	63.6	2.3	2.8	2.5	3.0	3.6	4.2	3.8	4.4	4.7	5.5	5.8	6.7	7.1	8.2	8.6	9.9
75.0	75.7	2.3	2.8	2.9	3.4	4.3	5.0	4.5	5.2	5.6	6.5	6.8	7.9	8.4	9.7	10.3	11.9
90.0	90.9	2.8	3.3	3.5	4.1	5.1	6.0	5.4	6.3	6.7	7.8	8.2	9.5	10.1	11.7	12.3	14.2
110.0	111.0	3.4	4.0	4.2	4.9	6.3	7.3	6.6	7.6	8.1	9.4	10.0	11.5	12.3	14.2	15.1	17.4
125.0	126.2	3.9	4.5	4.8	5.6	7.1	8.2	7.4	8.6	9.2	10.6	11.4	13.2	14	16.1	17.1	20.5
140.0	141.3	4.3	5.0	5.4	6.3	8.0	9.2	8.3	9.6	10.3	11.9	12.7	14.7	15.7	18.4	19.2	23.0
160.0	161.5	4.9	5.7	6.2	7.2	9.1	10.5	9.5	11.0	11.8	13.6	14.6	16.8	17.9	21.2	21.9	26.2
180.0	181.7	5.5	6.4	6.9	8.0	10.2	11.8	10.7	12.4	13.3	15.3	16.4	19.6	20.1	24.1	24.6	29.5
200.0	201.8	6.2	7.2	7.7	8.9	11.4	13.2	11.9	13.7	14.7	17.0	18.2	21.8	22.4	26.8	27.4	32.8
225.0	227.1	6.9	8.0	8.6	9.9	12.8	14.8	13.4	15.5	16.6	19.9	20.5	24.5	25.2	30.2	30.8	36.9
250.0	252.3	7.7	8.9	9.6	11.1	14.2	16.4	14.8	17.1	18.4	22.0	22.7	27.2	27.9	33.4	34.2	41.0
280.0	282.6	8.6	10.0	10.7	12.4	15.9	18.3	16.6	19.9	20.6	24.7	25.4	30.4	31.3	37.5	38.3	45.9
315.0	317.9	9.7	11.2	12.1	14.0	17.9	21.4	18.7	22.4	23.2	27.8	28.6	34.3	35.2	42.2	43.1	51.7
355.0	358.2	10.9	12.6	13.6	15.7	20.1	24.2	21.1	25.3	26.1	31.3	32.2	38.6	39.7	47.6	48.5	58.1
400.0	403.6	12.3	14.2	15.3	17.6	22.7	27.3	23.7	28.4	29.4	35.2	36.3	43.5	44.7	53.6	54.7	64.6
450	454.1	13.8	15.9	17.2	20.6	25.5	30.6	26.7	32.0	33.1	39.7	40.9	49.0	50.3	60.2	61.5	71.4
500	504.5	15.3	17.6	19.1	22.9	28.3	33.9	29.7	35.6	36.8	44.1	45.4	54.4	55.8	65.7	-	-
560	565.0	17.2	20.6	21.4	25.6	31.7	38.0	33.2	39.8	41.2	49.4	50.8	60.7	-	-	-	-
630	635.7	19.3	23.1	24.1	28.9	35.7	42.8	37.4	44.8	46.3	55.5	57.2	67.1	-	-	-	-
710	716.4	21.8	26.1	27.2	32.6	40.2	48.2	42.1	50.5	52.2	62.1	-	-	-	-	-	-
800	807.2	24.5	29.3	30.6	36.7	45.3	54.3	47.4	56.8	58.8	68.7	-	-	-	-	-	-
900	908.1	27.6	33.1	34.4	41.2	51.0	60.9	53.3	63.2	-	-	-	-	-	-	-	-
1000	1009	30.6	36.7	38.2	45.8	56.6	66.5	59.3	69.2	-	-	-	-	-	-	-	-
1200	1210	36.7	44.0	45.9	55.0	-	-	-	-	-	-	-	-	-	-	-	-
1400	1410	42.9	51.3	53.5	63.4	-	-	-	-	-	-	-	-	-	-	-	-
1600	1610	49.0	58.7	61.2	71.1	-	-	-	-	-	-	-	-	-	-	-	-

Note : Pressure Rating in : Kg/cm²

Material Grade PE 80

OD		PN 6		PN 8		PN 10		PN 12.5		PN 16
OD		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness
Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.
16.0	16.3	-	-	-	-	-	-	-	-	2.3	2.8
20.0	20.3	-	-	-	-	-	-	-	-	2.3	2.8
25.0	25.3	-	-	-	-	-	-	2.3	2.8	2.8	3.3
32.0	32.3	-	-	-	-	-	-	3.0	3.5	3.6	4.2
40.0	40.4	-	-	-	-	-	-	3.7	4.3	4.5	5.2
50.0	50.5	-	-	-	-	-	-	4.6	5.3	5.6	6.5
63.0	63.6	-	-	-	-	4.7	5.5	5.8	6.7	7.1	8.2
75.0	75.7	-	-	4.5	5.2	5.6	6.5	6.8	7.9	8.4	9.7
90.0	90.9	4.3	5.0	5.4	6.3	6.7	7.8	8.2	9.5	10.1	11.7
110.0	111.0	5.3	6.1	6.6	7.6	8.1	9.4	10.0	11.5	12.3	14.2
125.0	126.2	6.0	6.9	7.4	8.6	9.2	10.6	11.4	13.2	14.0	16.1
140.0	141.3	6.7	7.9	8.3	9.6	10.3	11.9	12.7	14.7	15.7	18.1
160.0	161.5	7.7	8.9	9.5	11.0	11.8	13.6	14.6	16.8	17.9	21.4
180.0	181.7	8.6	9.9	10.7	12.4	13.3	15.3	16.4	19.6	20.1	24.1
200.0	201.8	9.6	11.1	11.9	13.7	14.7	17.0	18.2	21.8	22.4	26.8
225.0	227.1	10.8	12.5	13.4	15.5	16.6	19.8	20.5	24.5	25.2	30.2
250.0	252.3	11.9	13.7	14.8	17.1	18.4	22.0	22.7	27.2	27.9	33.4
280.0	282.6	13.4	15.5	16.6	19.9	20.6	24.7	25.4	30.4	31.3	37.5
315.0	317.9	15.0	17.3	18.7	22.4	23.2	27.8	28.6	34.3	35.2	42.2
355.0	358.2	16.9	20.2	21.1	25.3	26.1	31.3	32.2	38.6	39.7	47.6
400.0	403.6	19.9	22.9	23.7	28.4	29.4	35.2	36.3	43.5	44.7	53.6
450	454.1	21.5	25.7	26.7	32.0	33.1	39.7	40.9	49.0	50.3	60.2
500	504.5	23.9	28.6	29.7	35.6	36.8	44.1	45.4	53.4	55.8	65.7
560	565.0	26.7	32.0	33.2	39.8	41.2	49.4	50.8	60.7	-	-
630	635.7	30.0	35.9	37.4	44.8	46.3	55.5	57.2	67.1	-	-
710	716.4	33.9	40.6	42.1	50.5	52.2	62.1	-	-	-	-
800	807.2	38.1	45.7	47.4	56.8	58.8	68.7	-	-	-	-
900	908.1	42.9	51.4	53.3	63.2	-	-	-	-	-	-
1000	1009	47.7	57.2	59.3	69.2	-	-	-	-	-	-
1200	1210	57.2	67.1	-	-	-	-	-	-	-	-
1400	1410	-	-	-	-	-	-	-	-	-	-
1600	1610	-	-	-	-	-	-	-	-	-	-

Note : Pressure Rating in : Kg/cm²

Material Grade PE 100

OD		PN 10		PN 12.5		PN 16
OD		Wall Thickness		Wall Thickness		Wall Thickness
Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.
32.0	32.3	-	-	-	-	3.0	3.5
40.0	40.4	-	-	-	-	3.7	4.3
50.0	50.5	-	-	-	-	4.6	5.3
63.0	63.6	-	-	4.7	5.5	5.8	6.7
75.0	75.7	4.5	5.2	5.6	6.5	6.8	7.9
90.0	90.9	5.4	6.3	6.7	7.8	8.2	9.5
110.0	111.0	6.6	7.6	8.1	9.4	10.0	11.5
125.0	126.2	7.4	8.6	9.2	10.6	11.4	13.2
140.0	141.3	8.3	9.6	10.3	11.9	12.7	14.7
160.0	161.5	9.5	11.0	11.8	13.6	14.6	16.8
180.0	181.7	10.7	12.4	13.9	15.3	16.4	19.6
200.0	201.8	11.9	13.7	14.7	17.0	18.2	21.8
225.0	227.1	13.4	15.5	16.6	19.9	20.5	24.5
250.0	252.3	14.8	17.1	18.4	22.0	22.7	27.2
280.0	282.6	16.6	19.9	20.6	24.7	25.4	30.4
315.0	317.9	18.7	22.4	23.2	27.8	28.6	34.3
355.0	358.2	21.1	25.3	26.1	31.3	32.2	38.6
400.0	403.6	23.7	28.4	29.4	35.2	36.3	43.5
450.0	454.1	26.7	32.0	33.1	39.7	40.9	49.0
500.0	504.5	29.7	35.6	36.8	44.1	45.4	54.4
560.0	565.0	33.2	39.8	41.2	49.4	50.8	60.7
630.0	635.7	37.4	44.8	46.2	55.4	57.2	67.1
710.0	716.4	42.1	50.5	52.2	62.1	-	-
800.0	807.2	47.4	56.8	58.8	68.7	-	-
900.0	908.1	53.3	63.2	-	-	-	-
1000.0	1009.0	59.3	69.2	-	-	-	-

Pressure Rating in : Kg/cm²

PE Pipe as per ISO:4984:95 (With Amendment)

Material Grade PE 63

All dimension are in mm

OD		PN 2.5		PN 4		PN 6		PN 8		PN 10		PN 12.5		PN 16
OD		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness
Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.
20.0	20.3	-	-	-	-	-	-	-	-	2.3	2.8	2.8	3.3	3.4	4.0
25.0	25.3	-	-	-	-	-	-	2.3	2.8	2.8	3.3	3.4	4.0	4.2	4.9
32.0	32.3	-	-	-	-	2.3	2.8	3.0	3.5	3.6	4.2	4.4	5.1	5.4	6.2
40.0	40.4	-	-	2.0	2.4	2.8	3.3	3.7	4.3	4.5	5.2	5.5	6.3	6.7	7.6
50.0	50.5	-	-	2.4	2.9	3.5	4.1	4.6	5.3	5.6	6.4	6.8	7.7	8.4	9.5
63.0	63.6	2.0	2.4	3.0	3.5	4.4	5.1	5.8	6.6	7.0	7.9	8.6	9.7	10.5	11.8
75.0	75.7	2.3	2.8	3.6	4.2	5.3	6.1	6.9	7.8	8.4	9.5	10.2	11.5	12.5	14.0
90.0	90.9	2.8	3.3	4.3	5.0	6.3	7.2	8.2	9.3	10.0	11.2	12.2	13.7	15.0	16.7
110.0	111.0	3.4	4.0	5.3	6.1	7.7	8.7	10.0	11.2	12.3	13.8	14.9	16.6	18.4	20.5
125.0	126.2	3.8	4.4	6.0	6.8	8.8	9.9	11.4	12.8	13.9	15.5	16.9	18.8	20.9	23.2
140.0	141.3	4.3	5.0	6.7	7.6	9.8	11.0	12.8	14.3	15.6	17.4	19.0	21.1	23.4	26.0
160.0	161.5	4.9	5.6	7.7	8.7	11.2	12.6	14.6	16.3	17.8	19.8	21.7	24.1	26.7	29.6
180.0	181.7	5.5	6.3	8.6	9.7	12.6	14.1	16.4	18.3	20.0	22.2	24.4	27.1	30.0	33.2
200.0	201.8	6.1	7.0	9.6	10.8	14.0	15.6	18.2	20.3	22.3	24.8	27.1	30.1	33.4	37.0
225.0	227.1	6.9	7.8	10.8	12.1	15.7	17.5	20.5	22.8	25.0	27.7	30.5	33.8	37.5	41.5
250.0	252.3	7.6	8.6	12.0	13.4	17.5	19.5	22.8	25.3	27.8	30.8	33.8	37.4	41.7	46.1
280.0	282.6	8.5	9.6	13.4	15.0	19.6	21.8	25.5	28.3	31.2	34.6	37.9	41.9	46.7	51.6
315.0	317.9	9.6	10.8	15.0	16.7	22.0	24.4	28.7	31.8	35.0	38.7	42.6	47.1	52.5	58.0
355.0	358.2	10.8	12.1	17.0	18.9	24.8	27.5	32.3	35.8	39.5	43.7	48.0	53.0	59.2	65.4
400.0	403.6	12.2	14.3	19.1	22.2	28.0	32.4	36.4	42.8	44.5	51.4	54.1	62.5	-	-
450.0	454.1	13.7	16.0	21.5	25.0	31.4	36.4	41.1	47.4	50.0	57.7	-	-	-	-
500.0	504.5	15.2	17.7	23.9	27.7	34.9	40.4	45.5	52.6	55.6	64.2	-	-	-	-
560.0	565.0	17.0	19.8	26.7	31.0	39.1	45.2	51.0	58.9	-	-	-	-	-	-
630.0	635.7	19.1	22.2	30.0	34.7	44.0	50.8	57.3	66.1	-	-	-	-	-	-
710.0	716.4	21.6	25.1	33.9	39.2	49.6	57.3	-	-	-	-	-	-	-	-
800.0	807.2	24.3	28.2	38.1	44.1	55.9	64.5	-	-	-	-	-	-	-	-
900.0	908.1	27.3	31.6	42.9	49.6	-	-	-	-	-	-	-	-	-	-
1000.0	1009.0	30.4	35.2	47.7	55.1	-	-	-	-	-	-	-	-	-	-

Note : Pressure Rating in : Kg/cm²

Material Grade PE 80

All dimension are in mm

OD		PN 6		PN 8		PN 10		PN 12.5		PN 16
OD		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness
Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.
20.0	20.3	-	-	-	-	-	-	2.3	2.8	2.8	3.3
25.0	25.3	-	-	-	-	2.3	2.8	2.8	3.3	3.5	4.1
32.0	32.3	-	-	2.4	2.9	3.0	3.5	3.6	4.2	4.5	5.2
40.0	40.4	2.3	2.8	3.0	3.5	3.7	4.3	4.5	5.2	5.6	6.4
50.0	50.5	2.9	3.4	3.8	4.4	4.6	5.3	5.6	6.4	6.9	7.8
63.0	63.6	3.6	4.2	4.7	5.4	5.8	6.6	7.0	7.9	8.7	9.8
75.0	75.7	4.3	5.0	5.6	6.4	6.9	7.8	8.4	9.5	10.4	11.7
90.0	90.9	5.1	5.9	6.7	7.6	8.2	9.3	10.0	11.2	12.5	14.0
110.0	111.0	6.3	7.2	8.2	9.3	10.0	11.2	12.3	13.8	15.2	17.0
125.0	126.2	7.1	8.1	9.3	10.5	11.4	12.8	13.9	15.5	17.3	19.3
140.0	141.3	8.0	9.0	10.4	11.7	12.8	14.3	15.6	17.4	19.4	21.6
160.0	161.5	9.1	10.3	11.9	13.3	14.6	16.3	17.8	19.8	22.1	24.6
180.0	181.7	10.2	11.5	13.4	15.0	16.4	18.3	20.0	22.2	24.9	27.6
200.0	201.8	11.4	12.8	14.9	16.6	18.2	20.3	22.3	24.8	27.6	30.6
225.0	227.1	12.8	14.3	16.7	18.6	20.5	22.8	25.0	27.7	31.1	34.5
250.0	252.3	14.2	15.9	18.6	20.7	22.8	25.3	27.8	30.8	34.5	38.2
280.0	282.6	15.9	17.7	20.8	23.1	25.5	28.3	31.2	34.6	38.7	42.8
315.0	317.9	17.9	19.9	23.4	26.0	28.7	31.8	35.0	38.7	43.5	48.1
355.0	358.2	20.1	22.4	26.3	29.2	32.3	35.8	39.5	43.7	49.0	54.1
400.0	403.6	22.7	26.4	29.7	34.4	36.4	42.1	44.5	51.4	55.2	63.7
450.0	454.1	25.5	29.6	33.4	38.7	41.0	47.7	50.0	57.7	-	-
500.0	504.5	28.4	32.9	37.1	42.9	45.5	52.6	55.6	64.2	-	-
560.0	565.0	31.7	36.7	41.5	48.0	51.0	58.9	-	-	-	-
630.0	635.7	35.7	41.3	46.7	54.0	57.3	66.1	-	-	-	-
710.0	716.4	40.2	46.5	52.6	60.7	-	-	-	-	-	-
800.0	807.2	45.3	52.3	-	-	-	-	-	-	-	-
900.0	908.1	51.0	58.9	-	-	-	-	-	-	-	-
1000.0	1009.0	56.7	65.5	-	-	-	-	-	-	-	-

Note : Pressure Rating in : Kg/cm²

Material Grade PE 100

All dimension are in mm

OD		PN 6		PN 8		PN 10		PN 12.5		PN 16
OD		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness		Wall Thickness
Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.
20.0	20.3	-	-	-	-	-	-	-	-	2.3	2.8
25.0	25.3	-	-	-	-	-	-	2.3	2.8	2.9	3.4
32.0	32.3	-	-	-	-	2.4	2.9	2.9	3.4	3.7	4.3
40.0	40.4	-	-	2.4	2.9	3.0	3.5	3.7	4.3	4.6	5.3
50.0	50.5	2.3	2.8	3.0	3.5	3.7	4.3	4.6	5.3	5.7	6.5
63.0	63.6	2.9	3.4	3.8	4.4	4.7	5.4	5.7	6.5	7.1	8.1
75.0	75.7	3.5	4.1	4.5	5.2	5.6	6.4	6.8	7.7	8.5	9.6
90.0	90.9	4.1	4.8	5.4	6.2	6.7	7.6	8.2	9.3	10.2	11.5
110.0	111.0	5.0	5.7	6.6	7.5	8.1	9.2	10.0	11.2	12.4	13.9
125.0	126.2	5.7	6.5	7.5	8.5	9.2	10.4	11.3	12.7	14.1	15.8
140.0	141.3	6.4	7.3	8.4	9.5	10.3	11.6	12.7	14.2	15.8	17.6
160.0	161.5	7.3	8.3	9.6	10.8	11.8	13.2	14.5	16.2	18.1	20.2
180.0	181.7	8.2	9.3	10.8	12.1	13.3	14.9	16.3	18.2	20.3	22.6
200.0	201.8	9.1	10.3	12.0	13.4	14.8	16.5	18.1	20.2	22.6	25.1
225.0	227.1	10.3	11.6	13.5	15.1	16.6	18.5	20.4	22.7	25.4	28.2
250.0	252.3	11.4	12.8	15.0	16.7	18.4	20.5	22.6	25.1	28.2	31.3
280.0	282.6	12.8	14.3	16.8	18.7	20.6	22.9	25.3	28.1	31.6	35.0
315.0	317.9	14.4	16.1	18.9	21.0	23.2	25.8	28.5	31.6	35.5	39.3
355.0	358.2	16.2	18.1	21.2	23.6	26.2	29.1	32.1	35.6	40.0	44.2
400.0	403.6	18.2	21.2	23.9	27.7	29.5	34.2	36.2	41.9	45.1	52.1
450.0	454.1	20.5	23.8	26.9	31.2	33.1	38.3	40.7	47.7	50.8	58.7
500.0	504.5	22.8	26.5	29.9	34.6	36.8	42.6	45.2	52.2	56.4	65.1
560.0	565.0	25.5	29.6	33.5	38.8	41.2	47.6	50.6	58.4	-	-
630.0	635.7	28.7	33.3	37.7	43.6	46.4	53.6	56.9	65.7	-	-
710.0	716.4	32.3	37.4	42.4	49.0	52.3	60.4	-	-	-	-
800.0	807.2	36.4	42.1	47.8	55.2	58.9	68.0	-	-	-	-
900.0	908.1	41.0	47.4	53.8	62.1	-	-	-	-	-	-
1000.0	1009.0	45.5	52.6	-	-	-	-	-	-	-	-

Note : Pressure Rating in : Kg/cm²

PE Pipe as per DIN:8074-99

OD		Pipe Series 25		Pipe Series 20		Pipe Series 16		Pipe Series 12.5		Pipe Series 10.5		Pipe Series 10		Pipe Series 8.3		Pipe Series 8.0		Pipe Series 6.3		Pipe Series 5.0		Pipe Series 4.0		Pipe Series 3.2		Pipe Series 2.5		Pipe Series 2.0
Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max	Min	Max
10	10.3	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	1.8	2.2	2.0	2.4
12	12.3	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	1.8	2.2	2.0	2.4	2.4	2.9
16	16.3	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	1.8	2.2	2.2	2.7	2.7	3.2	3.3	3.9
20	20.3	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	1.8	2.2	1.9	2.3	2.3	2.8	2.8	3.3	3.4	4.0	4.1	4.8
25	25.3	-	-	-	-	-	-	-	-	-	-	-	-	-	-	1.8	2.2	1.9	2.3	2.3	2.8	2.8	3.3	3.5	4.1	4.2	4.9	5.1	5.9
32	32.3	-	-	-	-	-	-	-	-	-	-	-	-	1.8	2.2	1.9	2.3	2.4	2.9	2.9	3.4	3.6	4.2	4.4	5.1	5.4	6.2	6.5	7.4
40	40.4	-	-	-	-	-	-	1.8	2.2	1.9	2.3	1.9	2.3	2.3	2.8	2.4	2.9	3.0	3.5	3.7	4.3	4.5	5.2	5.5	6.3	6.7	7.6	8.1	9.2
50	50.5	-	-	-	-	1.8	2.2	2.0	2.4	2.3	2.8	2.4	2.9	2.9	3.4	3.0	3.0	3.7	4.3	4.6	5.3	5.6	6.4	6.9	7.8	8.3	9.4	10.1	11.4
63	63.6	-	-	1.8	2.2	2.0	2.4	2.5	3.0	2.9	3.4	3.0	3.5	3.6	4.1	3.8	4.4	4.7	5.4	5.8	6.6	7.1	8.1	8.6	9.7	10.5	11.8	12.7	14.2
75	75.7	1.8	2.2	1.9	2.3	2.3	2.8	2.9	3.4	3.5	4.1	3.6	4.2	4.3	5.0	4.5	5.2	5.6	6.4	6.8	7.7	8.4	9.5	10.3	11.6	12.5	14.0	15.1	16.9
90	90.9	1.8	2.2	2.2	2.7	2.8	3.3	3.5	4.1	4.1	4.8	4.3	5.0	5.1	5.9	5.4	6.2	6.7	7.6	8.2	9.3	10.1	11.4	12.3	13.8	15.0	16.7	18.1	20.2
110	111.0	2.2	2.7	2.7	3.2	3.4	4.0	4.2	4.9	5.0	5.7	5.3	6.1	6.3	7.2	6.6	7.5	8.1	9.2	10.0	11.2	12.3	13.8	15.1	16.9	18.3	20.4	22.1	24.6
125	126.2	2.5	3.0	3.1	3.7	3.9	4.5	4.8	5.5	5.7	6.5	6.0	6.8	7.1	8.1	7.4	8.4	9.2	10.4	11.4	12.8	14.0	15.6	17.1	19.1	20.8	23.1	25.1	27.9
140	141.3	2.8	3.3	3.5	4.1	4.3	5.0	5.4	6.2	6.4	7.3	6.7	7.6	8.0	9.0	8.3	9.4	10.3	11.6	12.7	14.2	15.7	17.5	19.2	21.4	23.3	25.9	28.1	31.2
160	161.5	3.2	3.8	4.0	4.6	4.9	5.6	6.2	7.1	7.3	8.3	7.7	8.7	9.1	10.3	9.5	10.7	11.8	13.2	14.6	16.3	17.9	19.9	21.9	24.3	26.6	29.5	32.1	35.6
180	181.7	3.6	4.2	4.4	5.1	5.5	6.3	6.9	7.8	8.2	9.3	8.6	9.7	10.2	11.5	10.7	12.0	13.3	14.9	16.4	18.3	20.1	22.4	24.6	27.3	29.9	33.1	36.1	40.0
200	201.8	3.9	4.5	4.9	5.6	6.2	7.1	7.7	8.7	9.1	10.3	9.6	10.8	11.4	12.8	11.9	13.3	14.7	16.4	18.2	20.3	22.4	24.9	27.4	30.4	33.2	36.8	40.1	44.4
225	227.1	4.4	5.1	5.5	6.3	6.9	7.8	8.6	9.7	10.3	11.6	10.8	12.1	12.8	14.3	13.4	15.0	16.6	18.5	20.5	22.8	25.2	28.0	30.8	34.1	37.4	41.4	45.1	49.9
250	252.3	4.9	5.6	6.2	7.1	7.7	8.7	9.6	10.8	11.4	12.8	11.9	13.3	14.2	15.9	14.8	16.5	18.4	20.5	22.7	25.2	27.9	30.9	34.2	37.9	41.6	46.0	50.1	55.4
280	282.6	5.5	6.3	6.9	7.8	8.6	9.7	10.7	12.0	12.8	14.3	13.4	15.0	15.9	17.7	16.6	18.5	20.6	22.9	25.4	28.2	31.3	34.7	38.3	42.4	46.5	51.4	56.2	62.1
315	317.9	6.2	7.1	7.7	8.7	9.7	10.9	12.1	13.6	14.4	16.1	15.0	16.7	17.9	19.9	18.7	20.8	23.2	25.8	28.6	31.7	35.2	39.1	43.1	47.7	52.3	57.8	63.2	69.8
355	358.2	7.0	7.9	8.7	9.8	10.9	12.2	13.6	15.2	16.2	18.1	16.9	18.8	20.1	22.4	21.1	23.5	26.1	29.0	32.2	35.7	39.7	43.9	48.5	53.6	59.0	65.1	-	-
400	403.6	7.9	8.9	9.8	11.0	12.3	13.8	15.3	17.1	18.2	20.3	19.1	21.3	22.7	25.2	23.7	26.3	29.4	32.6	36.3	40.2	44.7	49.4	54.7	60.4	66.5	73.4	-	-
450	453.8	8.8	9.9	11.0	12.3	13.8	15.4	17.2	19.2	20.5	22.8	21.5	23.9	25.5	28.3	26.7	29.6	33.1	36.7	40.9	45.2	50.3	55.6	61.5	67.9	-	-	-	-
500	504.0	9.8	11.0	12.3	13.8	15.3	17.1	19.1	21.3	22.8	25.3	23.9	26.5	28.4	31.5	29.7	32.9	36.8	40.7	45.4	50.2	55.8	61.6	68.3	75.4	-	-	-	-
560	564.3	11.0	12.3	13.7	15.3	17.2	19.2	21.4	23.8	25.5	28.3	26.7	29.6	31.7	35.1	33.2	36.8	41.2	45.6	50.8	56.1	62.5	69.0	-	-	-	-	-	-
630	634.6	12.3	13.7	15.4	17.2	19.3	21.5	24.1	26.8	28.7	31.8	30.0	33.2	35.7	39.5	37.4	41.4	46.3	51.2	57.2	63.2	-	-	-	-	-	-	-	-
710	714.9	13.9	15.5	17.4	19.4	21.8	24.2	27.2	30.2	32.3	35.8	33.9	37.5	40.2	44.5	42.1	46.6	52.2	57.7	64.5	71.2	-	-	-	-	-	-	-	-
800	805.0	15.7	17.5	19.6	21.8	24.5	27.2	30.6	33.9	36.4	40.3	38.1	42.2	45.3	50.1	47.4	52.4	58.8	64.9	-	-	-	-	-	-	-	-	-	-
900	905.0	17.6	19.6	22.0	24.4	27.6	30.6	34.4	38.1	41.0	45.3	42.9	47.4	51.0	56.3	53.3	58.9	66.1	73.0	-	-	-	-	-	-	-	-	-	-
1000	1005.0	19.6	21.8	24.5	27.2	30.6	33.9	38.2	42.3	45.5	50.3	47.7	52.7	56.7	62.6	59.3	65.5	-	-	-	-	-	-	-	-	-	-	-	-
1200	1208.5	23.5	26.1	29.4	32.6	36.7	40.6	45.9	50.7	54.6	60.3	57.2	63.2	68.0	75.0	-	-	-	-	-	-	-	-	-	-	-	-	-	-
1400	1408.5	27.4	30.4	34.4	38.1	42.9	47.4	53.5	59.1	63.7	70.3	66.7	73.6	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
1600	1608.5	31.3	34.7	39.2	43.4	49.0	48.0	61.2	67.6	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-

Note : Pressure Rating in : Kg/cm²

PE Pipe as per ASTM D 3035 (PE 3408)

Nom. Dia.		Outside Dia.	Minimum Wall Thickness in mm
inch	mm	mm	DR32.5	DR26	DR21	DR17	DR15.5	DR13.5	DR11	DR9.3	DR9	DR7
½"	21	21.34	1.57	1.57	1.57	1.57	1.57	1.57	1.93	2.29	2.36	3.05
¾"	27	26.70	1.57	1.57	1.57	1.57	1.73	1.98	2.41	2.87	2.97	3.81
1"	33	33.40	1.57	1.57	1.60	1.96	2.13	2.46	3.05	3.58	3.71	4.78
1¼"	42	42.20	1.57	1.63	2.01	2.49	2.72	3.12	3.84	4.52	4.67	6.02
1½"	48	48.30	1.57	1.85	2.29	2.84	3.12	3.58	4.39	5.18	5.36	6.88
2"	60	60.30	1.85	2.31	2.87	3.56	3.89	4.47	5.49	6.48	6.71	8.61
3"	89	88.90	2.74	3.43	4.24	5.23	5.74	6.58	8.08	9.55	9.88	12.70
4"	114	114.30	3.51	4.39	5.44	6.73	7.37	8.46	10.39	12.29	12.70	16.33
5"	141	141.30	4.34	5.44	6.73	8.31	9.12	10.46	12.85	15.19	15.70	20.19
6"	168	168.28	5.18	6.48	8.00	9.91	10.85	12.47	15.29	18.08	18.69	24.03
8"	219	219.08	6.73	8.43	10.44	12.88	14.12	16.23	19.91	23.55	24.33	31.29
10"	273	273.05	8.41	10.49	13.00	16.05	17.63	20.22	24.82	29.36	30.33	39.01
12"	324	323.85	9.96	12.45	15.42	19.05	20.90	23.98	29.44	34.82	35.99	46.25
14"	357	355.60	10.95	13.67	16.94	20.93	22.94	26.34	32.33	38.23	39.52	50.80
16"	408	406.40	12.50	15.62	19.35	23.90	26.21	30.10	36.96	43.69	45.16	58.06
18"	459	457.20	14.07	17.58	21.77	26.90	29.49	33.86	41.55	49.15	50.80	65.30
20"	510	508.00	15.62	19.53	24.18	29.87	32.77	37.62	46.18	54.64	56.44	72.57
22"	561	558.80	16.94	21.49	26.62	32.87	36.04	41.40	50.80	60.10	62.08	79.83
24"	612	609.60	18.75	23.44	29.03	35.86	39.32	45.16	55.42	65.56	67.74	87.10
